MODEL : MLC LOAD CELL STRAIN GAUGE CONVERTER

■ GENERAL INFORMATION
The load cell strain gauge converter Model MLC/WLC is used in conjunction with bridge type strain gauges utilized in load cells, pressure transducers, etc.
It supplies the required excitation voltage and provides appropriate DC output signal.
Can handle up to 4 load cells in paralle.

■ FEATURES
tr bgcolor=#FFFFFF>

ITEM	SPECFICATIONS
LOAD CELL TO BE COMBINED	BRIDGE RESISTANCE 80Ω OR MORE RATED OUTPUT VOLTAGE 2mV/V OTHERS
APPLIED VOLTAGE	DC 5V ~ DC 12V
OUTPUT	DC VOLTAGE or DC CURRENT SIGNAL
ACCURACY	±0.2% of F.S
REPEATBILITY	±0.1% of F.S
RESPONSE TIME	LESS THAN 0.5sec(0~90%)
INSULATION RESISTANCE	GREATER THAN 100㏁ (DC 500V)
DIELECTRIC STRENGTH	INPUT-POWER AC 1000V INPUT-OUTPUT AC 1000V (1 MIN) INPUT-GND AC1000V
AMBIENT TEMPERATURE	-5 ~ 60℃
HUMIDITY	LESS THAN 90% RH
